100W CO2 Laser Power Supply for 80w 90w 100w 120w Laser Tube Laser Cutter Power Supply MYJG-100 by Amazon.com

$178.00$198.00

Price last update: 23/05/2025

View deal

• ApplicationReplacement Parts for CO2 Laser Tube and CO2 Laser Engraver /Cutter / Marker.

Description

Product description
Your Laser Power Supply Expert
Hunst is a leader in the laser engraving industry because of our reliable, high-performance, and cost-effective laser engraving machines and accessories.
Our 80~100W laser power supply has a fast response time and provides reliable and efficient power for your laser engraver or cutter.
Simple TTL level control and open circuit protection, easy to use and longer service life.
DGHUNST can meet all your laser engraving needs.
Characteristics
MYJG-100W
Good compatibility
This power supply can be applied to 80-100W tubes made by various factories.
Alto desempenho de longa duração
Fast response output open circuit protection
Application
Sculpt and cut acrylic, fabric, bicolor sheet and rubber, etc.
Advantages
Effect and fast response speed
High performance cutting power
It can also extend the life of the laser tube.
Easy control: manual TEST button TTL level control
Specifications
Input Voltage
AC110V
AC Frenquency
47-440HZ
Max Input Power
500W
Max Input Current
3A
Maximum Output Voltage
DC35KV DC5V
Maximum Output Current
DC30mA
Efficiency
>/=91%(Full Load)
MTBF
>/=30000 Hours
Response speed
<=1ms(Time from the TTL Signal is given to the output current up to 90% pre-setting current)
Withstand Voltage
Input-output, input-Enclosure: AC1500V 10mA 60s, Output cathode is connected with enclosure.
Environment
Operating temperature:(-10-40)degree Clesius, Relative humidity:<=90%
Cooling
Force-Air Cooling(FAC)
port definition table
Port 1 ( FG AC AC
Port 2 (H L P G IN 5V)
FG
Connect with G Internal, and Connect the Power Supply Shell
AC AC
AC 110V/220V Input
H
Laser control switch (active high)
L
Interruptor de control de láser (activo bajo)
P
water protection
G
Grounding: The foot must be connected to the laser machine housing and properly grounded.
IN
0-5V analog signal control input, also can use 5V PWM signal to control.
5V
Output 5V, max current 50mA.
Detail picture
Reliable quality performance
Our 80~100W laser power supplies provide excellent performance, high efficiency and fast response time.
Use our safe, stable and powerful power supply to extend the service life and make full use of your 80~100W laser tube.
Wide range of applications
With good compatibility, it can be applied to the laser tubes of many manufacturers of laser engraving machines.
Simple installation
Each connection port is clearly marked, which is convenient and quick to install.
110V/220V optional
The power supply also has a physical test button for fault detection, allowing you to easily troubleshoot.
Wavelength
10.6um
10.6um
10.6um
10.6um
10.6um
1064nm
